Network TAPs
Cubro OPTOSLIM TAPs Series give real-time monitoring access to a physical optical data link with no network performance degradation or disruption. Since the optical TAPs are fully passive (no power supply needed), it is no risk to put them in an active link. These TAPs bring additional optical power loss on the active link depending on the splitting ratio used.
- Full transparency allows user to use optical TAPs for all protocols or data rates up to 100 Gbit
- No power supply needed
- Flexible and scalable
- Every used splitter inside the optical TAP is carefully handled • Insertion loss is measured before the unit leaves to the customer
- Split ratio can be delivered on demand for single mode version
EXA32400: 400G Advanced Network Packet Broker
The EXA32400 is a high-performance advanced network packet broker designed to optimize network traffic flow to security, monitoring, and management tools.
Featuring 32 x 100G/400G QSFP28/QSFP-DD interfaces, the EXA32400 empowers your network with an extensive range of connectivity options. With breakout cable support on the 400G QSFP-DD ports, you can easily connect individual 4 x 100G interfaces, providing remarkable flexibility for your network requirements. The unit is built on an advanced multi-core, industry-leading programmable switch chip architecture, ensuring exceptional throughput and performance.
Key Features:
- Filters and load-balances traffic from 100 and 400 Gbps links to multiple monitoring tools
- 32 x 100/400 Gbps (QSFP28/QSFP-DD)
- Breakout to 128 x 100G supported
- Supports data burst buffering
- Packet slicing support (any configurable packet size)
- IPv6 support
- Tunnel header stripping
- No additional port licensing fees or software feature licensing. All features and applications included in the unit price.
EXA32100A : Cubro Session Master
The Session master EXA32100 is a Network Packet Broker and network controller switch that aggregates, filters and load balances network traffic sent to network monitoring, security and management tools.
Session master EXA32100 allows you to filter and load-balance traffic from 40 or 100-Gbps link to multiple 40-Gbps monitoring tools or aggregate multiple 1-Gbps links to 10 or 100-Gbps monitoring tools. Packet master EX20400 also supports traffic modification as well as changing,removing and adding VLAN‘s, MPLS, VXLAN,NVGRE / MLAG / GENEVE
Optical Extended Functions:
- L7 packet based filtering
- Software defined Counters
- Flexible Key Creation (Parse)
- Flexible Tables (Lookup)
- Flexible Packet editing (Modify)
- Integrated Traffic Management (Queue)
- Create new metrics (Count)
Ports
- 32 x QSFP28 or zQSFP 100 Gbps (LR4)
- 25 Gbps MAS support
- 1 x 10/100/1000 Base-T (Management)
- 1 x RS232 Console
Packetmaster AGG-48600
The Packetmaster AGG-48600 is a network packet broker design based on newest and the most advanced ASIC available on the market. It is built with an advanced Cavium multi-core host controller and the biggest network buffer RAM in the industry.
The big manageable buffer size helps to overcome bursting issues in aggregation applications. The Cavium multi-core host controller supports application to faster interact with the network ASIC.
Advantages of AGG-48600
- 10 Gbit / 25 Gbit / 40 Gbit / 100 Gbit
- Layer 4 support
- No optical modules blocking
- Non-blocking backplane
- Link / Port Aggregation, Aggregation many to any, and any to many at all link speeds
- Low power design
- Python script App manager
